Product Details:
|
| Item Name: | Exhaust Pipes Stainless Steel Wire Braided Flexible Bellow For Front Exhaust System | Inside Diameter: | 1.75 Inch / 45mm |
|---|---|---|---|
| Materials: | Stainless Steel 201 / 304 | Overall Length: | 252mm |
| Structure: | Inner Braided + Outer Braided + Nipple / Extension Pipe | Cap / Collar Materials: | Aluminized Steel |
| Bellow No.: | Single Layer Or Double Layers | Application: | Car / Truck Exhaust System |
| Feature: | No Leak And Suitable Flexibility | ||
| High Light: | id 45mm ss flexible bellows,front exhaust system ss flexible bellows,304 grade ss flexible bellows |
||
Short introduction of exhaust flexible pipe:
| Discription | Flexible Bellow Pipe | Parts No. | YP-EXF225 |
| Inside diameter | 1.75 inch / 45mm | Style | flexible pipe with nipple / extension pipe |
|
Bellow length
|
6 inch / 152mm | Overall lenth | 10 inch / 252mm |
| Flex pipe Material | Stainless steel 304 201 | Joint Material | aluminized steel |
| Car Make | Universal | Application | Exhaust pipe of various of car, bus, truck, and so on. |
| Packing | Plastic bag and seaworthy box | Package Quantity | 1 pcs |
| Brand | YP | Place of Origin | Tianjin, China |
| Certificate | ISO | Warranty | One Year |
Application of exhaust flexible pipe:
The flexible bellow pipe is an important part of car exhaust system. When you accelerate, The car’s engine moves back and forth on rubber engine mounts. The flexible pipe allows for flexibility in your exhaust system, preventing the engine’s movement and vibrations from damaging and cracking the exhaust pipe.
| Inner Diameter (ID) | Flex Length(L) | Overall Length(L) |
| 1-3/4” (45mm) | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 48mm | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 2”(50.8mm) | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 54mm | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 2-1/4”(57.2mm) | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 2-1/2”(63.5mm) | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| 3”(76.2mm) | 4”(102mm) | 8”(203mm) |
| 6”(152mm) | 10”(254mm) | |
| 8”(203mm) | 12”(305mm) | |
| 10”(254mm) | 14”(356mm) | |
| Note: Customized size are available | ||
Packaging of exhaust flexible pipe:
25pcs per carton. film bag for each product. Mark as request.
FAQ
1. Q: How about the payment terms?
T/T 100% for order value less than $3000. Otherwise, 30% deposit in advance, the balance against the copy of B/L. It can be also discussed when we have friendly relationship.
2. How about Delivery time?
We can produce 100,00 pcs per month. Normally, 5-8 days if stocks available.
3. Q:Can I get a sample?
For sure, we are willing to supply samples free for your quality checking. But the freight fee is in buyer side.
4. Q : What's the price?
Reasonable price, competitive price, and acceptable prices, which are all based on good quality.
Contact me on line or by email. We will give you fast and best offer. Thanks.
