2 Inch 3.5L Car Catalytic Converter

Recommedation is good. Reception is professional. Wish to place more orders with flexible exhaust pipe.

—— Rodrigo Favaro

Good company with nice service and high quality for exhaust muffler.

—— John Hermans

Thanks for your good after-sale service. Popular design for the exhaust pipe and muffler system.

—— Aidyn Hadiev

Good support. High quality of exhaust clamps. We'll reorder soon.

—— OAKANTSE Lucas

I'm Online Chat Now

2 Inch 3.5L Car Catalytic Converter

2 Inch 3.5L Car Catalytic Converter
2 Inch 3.5L Car Catalytic Converter 2 Inch 3.5L Car Catalytic Converter 2 Inch 3.5L Car Catalytic Converter

Large Image :  2 Inch 3.5L Car Catalytic Converter

Product Details:
Place of Origin: Hebei
Brand Name: YP
Certification: ISO
Model Number: YP-EXCC020
Payment & Shipping Terms:
Minimum Order Quantity: 50
Price: Negotiable
Packaging Details: Plastic bag + seaworthy carton
Delivery Time: 5-8 days if stocks available
Payment Terms: L/C T/T WESTERN UNION MONEYGRAM
Supply Ability: 10000 Pieces Per Month
Detailed Product Description
Product: Stainless Steel Auto Universal Performance Catalytic Converter Materials: SUS409 / 304 Stainless Steel
Inlet/outlet: 2" Type: Three Way
Car Make: Universal Emission Standard: Euro2/3/4 EPA CARB
Displacement: 2.0L-3.5L Cell: 400cpsi
Quality: ISO 9001 TS 16949 Quality Control System Ceramic Honeycomb Substrate: 120*80*50mm 2 Pcs
High Light:

3.5L Car Catalytic Converter

,

SUS409 Car Catalytic Converter

,

3.5L 2 inch universal catalytic converter

What is catlytic converter?


A catalytic converter is a device that helps to turn toxic byproducts found in an engine into less toxic substances through the use of chemical reactions. As a car runs, the catalytic converter turns pollutants into less harmful substances before they leave a vehicle through the exhaust pipe. This can help to clean up the air significantly!



Application



While they are found in standard automobiles, they are also in many other machines. This includes buses, trucks, motorcycles, and forklifts, just to name a few. Think of all the vehicles that exist and how much pollution they cause. To combat the pollution, many machines utilize catalytic converters.



Working principle



2 Inch 3.5L Car Catalytic Converter 0



The catalytic converter's construction is as follows:



  1. The catalyst support or substrate. For automotive catalytic converters, the core is usually a ceramic monolith that has a honeycomb structure (commonly square, not hexagonal).
  2. The washcoat. A washcoat is a carrier for the catalytic materials and is used to disperse the materials over a large surface area. Aluminum oxide, titanium dioxide, silicon dioxide, or a mixture of silica and alumina can be used. The catalytic materials are suspended in the washcoat prior to applying to the core. Washcoat materials are selected to form a rough, irregular surface, which greatly increases the surface area compared to the smooth surface of the bare substrate. This in turn maximizes the catalytically active surface available to react with the engine exhaust. The coat must retain its surface area and prevent sintering of the catalytic metal particles even at high temperatures (1000 °C).
  3. Ceria or ceria-zirconia. These oxides are mainly added as oxygen storage promoters.
  4. The catalyst itself is most often a mix of precious metals, mostly from the platinum group. Platinum is the most active catalyst and is widely used, but is not suitable for all applications because of unwanted additional reactions and high cost. Palladium and rhodium are two other precious metals used. Rhodium is used as a reduction catalyst, palladium is used as an oxidation catalyst, and platinum is used both for reduction and oxidation.

Upon failure, a catalytic converter can be recycled into scrap. The precious metals inside the converter, including platinum, palladium, and rhodium, are extracted.



2 Inch 3.5L Car Catalytic Converter 1



Packaging and delivery





Package 1pc/white paper box, 10pcs/master carton
Delivery method By express, By air, By sea
Delivery time Depends on order quantity
Shipment terms EXW, FOB CHINA, CNF CHINA, CIF CHINA



2 Inch 3.5L Car Catalytic Converter 2



Related products



We have a complete offerings of mufflers & resonators for all segments of the industry.  Our mufflers & resonators are the perfect fit and suitable for all naturally aspirated and forced induction applications. Not only those, we also supply exhuast flex pipe and clamps in dozen sizes and designs as customer's request.



2 Inch 3.5L Car Catalytic Converter 3
