Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged

100mm duct hose clamp

adjustable bolt duct hose clamp

100mm v band clamp

Place of Origin:

China

CONTACT US
Request A Quote
Product Details
Name:
Adjustable Bolt Lock Ring Hose Clamp
Width:
28mm
Industry:
Dust Collection, Air Handling, Particle Transportation
Surface:
Galvanised
Material:
Carbon Steel (or Stainless Steel 304)
Diameter:
80mm-600mm
Lock Mechanism:
Adjustable Bolt
Sealing Gasket:
TPE Or EPDM
Feature:
Air Tight , Quick Lock
Thickness:
1.0mm 1.2mm
Payment & Shipping Terms
Minimum Order Quantity
1 pc
Price
USD$ 1.95/PC
Packaging Details
carton , wooden case
Delivery Time
5-7days if stock, 20-25days for mass order
Payment Terms
L/C, T/T, Western Union
Supply Ability
10000PCS/MONTH
Product Description

Adjustable Bolt Lock Ring Hose Clamp For Dust Extraction Flanged Duct



Product Description:



This is a new design quick release latch air duct clamp developed by Yunpeng, also called the bolted duct clamp, usually it’s used for connecting 1.0mm/1.2mm modular ducts,like modular bends, straight pie, but also applied to 0.5-0.8mm HVAC system ventilation ducting, particle transport system, animal feed industry pipework system which has lipped pipe ends, another quick release lever adjustable duct clamp is also available.

There is a V groove at the clamping joint of the pipe clamp which makes the operation convenient and the clamping very tight.



If you have different clamp design or idea, please feel free to discuss with us, we have many years’ experience on various types of clamps.



Material Mild Steel or stainless steel 304 for food grade industry
Surface Galvanised or natual stainless surface
Diameter  80mm-600mm or  3"-24"
Thickness 1.0mm / 1.2mm
Lock set Adjustable bolts



Specification:

Our standard available sizes are from 80mm(3")  to 600mm (24") , customized design and size requirement are welcome.



Adjustable Bolt Quick Release Pipe Clamp



Φ Diameter mm Product Code A mm H mm Thickness mm
80 LMG80 28 8 1.0
100 LMG100 28 8 1.0
120 LMG120 28 8 1.0
125 LMG125 28 8 1.0
140 LMG140 28 8 1.0
150 LMG150 28 8 1.0
160 LMG160 28 8 1.0
180 LMG180 28 8 1.0
200 LMG200 28 8 1.0
225 LMG225 28 8 1.0
250 LMG250 28 8 1.0
275 LMG275 28 8 1.0
300 LMG300 28 8 1.0
315 LMG315 28 8 1.2
350 LMG350 28 8 1.2
400 LMG400 28 8 1.2
450 LMG450 28 8 1.2
500 LMG500 28 8 1.2
550 LMG550 28 8 1.2
600 LMG600 28 8 1.2



LMG TYPE:



Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 0

BMG TYPE:

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 1

Application:



Quick lock duct clamp could be used for standard modular ducting with flange or rolled edge for dust collection, dust extraction, air filtration and particle transport system.

And any other pipeline which needs the air tight requirement.



Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 2



Packing of air duct clamp:



Cartons or wooden cases for mixed sizes.



Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 3

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 4

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 5

We accept many OEM clamp production:

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 6

Company:



We develop and manufacture modular ducting, circular ductwork in galvanised steel, mild steel and stainless steel, along with a full range of ancillary fittings and components. Our ducting system adopts the flanged/lip edge quick connection way, allowing rapid installation with no special tools needed. Products including pressed bends / segmented bends( R=1.5D, R=2D , material involving hot dip galvanised steel sheet DX51D + 275 , mild steel , stainless steel,in thickness 0.75mm, 1.0mm, 1.2mm,2.0mm,3.0mm, diameters from 80mm to 300mm, at 15, 30, 45, 60 and 90 degrees angles ); straight duct pipe, rapid lock pull ring , wide rings, slim rings, flanges,sliding dampers/blast gate in manual and pneumatic, butterfly dampers, clip bands, branch and trouser pieces, throttle valves, diverters, pipe couplings, and many other customized clamps etc.

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 7

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 8



Contact Becky for more information if you have requirement on this clamp:

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 9

Adjustable Bolt Lock Ring 100mm Duct Hose Clamp For Dust Extraction Flanged 10
