2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe

2.5x4 Stainless Steel Exhaust Flex Pipe

Plain Stainless Steel Exhaust Flex Pipe

2.5x4 Stainless Exhaust Flex Pipe

Place of Origin:

China

CONTACT US
Request A Quote
Product Details
Other Name:
Stainless Steel Exhaust Flex Bellow Pipe
Car Make:
Universal
Pipe Type:
With Interlock Liner
Warranty:
1 Year
Ply:
1 Ply Or 2 Ply Bellow
Size:
1.5" * 6"
MOQ:
1pc
Application:
Vehicle Exhaust System
Length:
4”-10”
Finish:
Plain
Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
USD$ 1.1--8.99 /PC
Packaging Details
carton
Delivery Time
10-20DAYS
Payment Terms
L/C, T/T, Western Union
Supply Ability
80000PCS/MONTH
Product Description


2.5" x 4" Inch Stainless Steel Cat-Backs Headers Exhaust Flex Pipe Interlocking Liner Coupler

Product Introduction:

This Stainless Steel Flex Couplers have bellows with interlocking lining to help increased exhaust flow through the coupler, and prevent excessive back pressure to build. This coupler is made of ss 304 throughout, including the weld rings, so it will not rust, the size is 2.5inch , and 4 inch long.

Stainless steel exhaust flexible pipes is a part of the engine exhaust system of the car. They're constructed with 1 or 2-ply bellows and together with a seamless, convoluted inner core—increasing flexibility in order to reduce vibrations and prevent exhaust leaks that allows your car to be more comfortable and enjoyable in use. Such flex pipes are provided in a variety of lengths, diameters, and many styles.

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 0

Types of YP exhaust Flexible PIpe:

We supply a variety of exhaust flex. pipe for the whole world, especially Middle-East countries(Syria, Lebanon, Iraq, Iran, Israel,Jordan, Egypt, Kuwait, Yemen,  Algeria, Morocco Afghanistan, Pakistan), Southeast Asia , USA, Canada, France, Poland,Switzerland, Spain, Russia, South America and many other countries.

Some popular models of our flexible pipe:

1. Braided Flexible pipe with inner bellow, this is a single braided pipe, inside is the bellow pipe, no braided linner any more, it is great for light use.

2. Braided Flexible pipe with braided liner, there added another layer of braided linner compared with the first model, bellow is in the middle, this provides better flexibility and longer life, better for medium use.

3. Bellows with interlock, there added an interlock tube with bellows in the middle, the key is the interlock pipe, this has proved to reduce vibration and noise and lasts the longest. There is an interlocked pipe visible when you look through the middle. This is manufactured for heavy use.

4. Braided Flexible Pipe with Nipples/tubes this is an easy part with welding tube at the end, customers don't need to do extra welding again.

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 1
Common Model Specifications:


Part No.innner dia. inchinner diamater mmLength inchLength mm
YP134041-3/4"454"102
YP134061-3/4"456"152
YP134071-3/4"457"178
YP134081-3/4"458"203
YP134091-3/4"459"230
YP134101-3/4"4510"254
YP134111-3/4"4511"280
YP134121-3/4"4512"305
YP200042"50.84"102
YP200062"50.86"152
YP200082"50.88"203
YP200092"50.89"230
YP200102"50.810"254
YP200112"50.811"280
YP200122"50.812"305
YP214042-1/4"57.24"102
YP214062-1/4"57.26"152
YP214082-1/4"57.28"203
YP214092-1/4"57.29"230
YP214102-1/4"57.210"254
YP214112-1/4"57.211"280
YP214122-1/4"57.212"305
YP212042-1/2" / 3"63.5 / 76.24"102
YP212062-1/2" / 3"63.5 / 76.26"152
YP212082-1/2" / 3"63.5 / 76.28"203
YP212092-1/2" / 3"63.5 / 76.29"230
YP212102-1/2" / 3"63.5 / 76.210"254
YP212112-1/2" / 3"63.5 / 76.211"280
YP212122-1/2" / 3"63.5 / 76.212"305


Drawing for reference:

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 2

Factory Workshop:

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 3

Pipe Packing and Delivery Time:

Usually, 25pcs into a carton, each piece is wrapped with a plastic bag or sealed in plastic, then into pallet.
Delivery time is 7-25Days as differenct quantities.

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 4
Contact Us:

2.5x4 Inch Plain Stainless Steel Exhaust Flex Pipe 5

If any inquiry, pls contac us any time :

Becky Shao
Email : becky@ypmachinery.com
Whatsapp / Cell / Wechat: +86-15933316077
